Round LED spacer 90 degrees
Application
LED spacers
Material
Nylon
Colour
Black Natural
Angle
90
Flame class
UL-94-V2
| Partnumber | Figure | A | B |
|---|---|---|---|
| 28016183 | 2 | 7 | 2.5 |
| 28016160 | 5 | LED1L-5 | |
| 28016164 | 9 | 3 | LED1L-9 |
| 28016185 | 10 | 2.9 | LEKH-10 |
| 28016180 | 3 | 2.9 | LEKH-3 |
| 28016165 | 10 | 2.5 | LED1L-10 |
| 28016184 | 9 | 2.9 | LEKH-9 |
| 28016181 | 4.5 | 2.5 | LEKH-4.5 |
| 28016182 | 6 | 2.5 | LEKH-6 |
| 28016162 | 7 | 3 | LED1L-7 |
| 28016163 | 8 | 3 | LED1L-8 |
| 28016161 | 6 | 3 | LED1L-6 |
