Receptacles 2.8 (.110) series, straight type, Low insertion based on standard design
Terminal version
On reel
Terminal type
Receptacles
Mating tab width
2.8
Crimping press
On request
| Partnumber | Wire size | AWG | Tab thickn. | Material | Mat. thickn. | Parts x reel | Ø Insul. |
|---|---|---|---|---|---|---|---|
| 32480432 | 0.1 to 0.3 | 26-22 | 0.8 | Bronze Sn | 0.25 | 15000 | 1 to 1.8 |
| 32480202 | 0.1 to 0.3 | 26-22 | 0.5 | Brass Sn | 0.25 | 15000 | 1 to 1.8 |
| 32480430 | 0.1 to 0.3 | 26-22 | 0.8 | Bronze | 0.25 | 15000 | 1 to 1.8 |
| 32480200 | 0.1 to 0.3 | 26-22 | 0.5 | Brass | 0.25 | 15000 | 1 to 1.8 |
| 32480402 | 0.1 to 0.3 | 26-22 | 0.8 | Brass Sn | 0.25 | 15000 | 1 to 1.8 |
| 32480232 | 0.1 to 0.3 | 26-22 | 0.5 | Bronze Sn | 0.25 | 15000 | 1 to 1.8 |
| 32480400 | 0.1 to 0.3 | 26-22 | 0.8 | Brass | 0.25 | 15000 | 1 to 1.8 |
| 32480230 | 0.1 to 0.3 | 26-22 | 0.5 | Bronze | 0.25 | 15000 | 1 to 1.8 |
