Receptacles 2.8 (.110) series, straight type, standard terminals
Terminal version
On reel
Terminal type
Receptacles
Mating tab width
2.8
Crimping press
On request
| Partnumber | Wire size | AWG | Tab thickn. | Material | Mat. thickn. | Parts x reel | Ø Insul. | Approvals |
|---|---|---|---|---|---|---|---|---|
| 32440430 | 0.1 to 0.3 | 26-22 | 0.8 | Bronze | 0.25 | 15000 | 1 to 1.8 | - |
| 32440432 | 0.1 to 0.3 | 26-22 | 0.8 | Bronze Sn | 0.25 | 15000 | 1 to 1.8 | - |
| 32441000 | 0.5 to 1 | 20-18 | 0.8 | Brass | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32441002 | 0.5 to 1 | 20-18 | 0.8 | Brass Sn | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32440402 | 0.1 to 0.3 | 26-22 | 0.8 | Brass Sn | 0.25 | 15000 | 1 to 1.8 | - |
| 32440802 | 0.5 to 1 | 20-18 | 0.5 | Brass Sn | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32440200 | 0.1 to 0.3 | 26-22 | 0.5 | Brass | 0.25 | 15000 | 1 to 1.8 | - |
| 32440800 | 0.5 to 1 | 20-18 | 0.5 | Brass | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32440232 | 0.1 to 0.3 | 26-22 | 0.5 | Bronze Sn | 0.25 | 15000 | 1 to 1.8 | - |
| 32440832 | 0.5 to 1 | 20-18 | 0.5 | Bronze Sn | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32441030 | 0.5 to 1 | 20-18 | 0.8 | Bronze | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32440830 | 0.5 to 1 | 20-18 | 0.5 | Bronze | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32441032 | 0.5 to 1 | 20-18 | 0.8 | Bronze Sn | 0.25 | 15000 | 1.8 to 2.5 | UL |
| 32440230 | 0.1 to 0.3 | 26-22 | 0.5 | Bronze | 0.25 | 15000 | 1 to 1.8 | - |
| 32440202 | 0.1 to 0.3 | 26-22 | 0.5 | Brass Sn | 0.25 | 15000 | 1 to 1.8 | - |
| 32440400 | 0.1 to 0.3 | 26-22 | 0.8 | Brass | 0.25 | 15000 | 1 to 1.8 | - |
