LiYY-OZ multicore cables, blue outer sheath
Nom. voltage
300/500
Temperature
-5 to 70°C
Cable type
Multicore cable
Test voltage
3000
Norm
LiYY-OZ, DIN VDE
Conductor size
0.75-1.5 mm2
No. conductors
2 to 25
Insulation colour
Blue, RAL 5015
Core colours
Black numbered
Norm & Approvals
LiYY, LiYCY
Insulation material
PVC
Temperature max.
70°C
Insulation properties
Flame retardant Self-extinguishing
| Partnumber | Number inner cores | Conductor size mm2 |
|---|---|---|
| 47071504 | 4 | 1.5 |
| 47070704 | 4 | 0.75 |
| 47071005 | 5 | 1 |
| 47071525 | 25 | 1.5 |
| 47071025 | 25 | 1 |
| 47071002 | 2 | 1 |
| 47071012 | 12 | 1 |
| 47071512 | 12 | 1.5 |
| 47071018 | 18 | 1 |
| 47071004 | 4 | 1 |
| 47071518 | 18 | 1.5 |
| 47070703 | 3 | 0.75 |
| 47070705 | 5 | 0.75 |
| 47070712 | 12 | 0.75 |
| 47070718 | 18 | 0.75 |
| 47070725 | 25 | 0.75 |
| 47071502 | 2 | 1.5 |
| 47070707 | 7 | 0.75 |
| 47071007 | 7 | 1 |
| 47071003 | 3 | 1 |
| 47070702 | 2 | 0.75 |
| 47071507 | 7 | 1.5 |
| 47071503 | 3 | 1.5 |
| 47071505 | 5 | 1.5 |
