Nickel-plated brass PG cable glands, hexagonal lower part, IP68, special sealing for individual wires of multicore cable
Application
Cable glands
PG or metric
PG
Material
Brass
Protection
IP68
| Partnumber | Cable diameter | Size | SW | Length of thread (I1) | Cables |
|---|---|---|---|---|---|
| mm | |||||
| 18008401 | 2.3 to 3.5 | PG 9 | 18 | 6 | 2x |
| 18008427 | 4 to 5 | PG36 | 50 | 8 | 6x |
| 18008416 | 5 to 7 | PG16 | 28 | 6 | 3x |
| 18008406 | 3 to 5 | PG13.5 | 24 | 6 | 2x |
| 18008415 | 4 to 6 | PG16 | 24 | 6 | 3x |
| 18008400 | 1.5 to 2.7 | PG 9 | 18 | 6 | 2x |
| 18008417 | 3.5 to 5 | PG16 | 24 | 6 | 4x |
| 18008423 | 7 to 9 | PG29 | 40 | 8 | 3x |
| 18008411 | 3 to 5 | PG16 | 24 | 6 | 2x |
| 18008420 | 6 to 9 | PG21 | 32 | 7.5 | 3x |
| 18008404 | 3.5 to 5 | PG11 | 22 | 6 | 2x |
| 18008422 | 9.5 to 12 | PG29 | 40 | 8 | 2x |
| 18008421 | 6 to 8 | PG21 | 32 | 7.5 | 4x |
| 18008403 | 3 to 4 | PG11 | 22 | 6 | 2x |
| 18008425 | 8 to 10 | PG29 | 40 | 8 | 4x |
| 18008413 | 6 to 8 | PG16 | 24 | 6 | 2x |
| 18008405 | 5 to 7 | PG11 | 22 | 6 | 2x |
| 18008426 | 8 to 11 | PG36 | 50 | 8 | 2x |
| 18008428 | 14 to 16 | PG42 | 58 | 10 | 3x |
| 18008409 | 4 to 6 | PG13.5 | 24 | 6 | 3x |
| 18008402 | 3.5 to 5 | PG 9 | 18 | 6 | 2x |
| 18008408 | 6 to 8 | PG13.5 | 24 | 6 | 2x |
| 18008418 | 6 to 9 | PG21 | 32 | 7.5 | 2x |
| 18008412 | 5 to 7 | PG16 | 24 | 6 | 2x |
| 18008410 | 3.5 to 5 | PG13.5 | 24 | 6 | 4x |
| 18008414 | 7 to 9 | PG16 | 28 | 6 | 2x |
| 18008407 | 5 to 7 | PG13.5 | 24 | 6 | 2x |
| 18008419 | 8.5 to 11 | PG21 | 32 | 7.5 | 2x |
| 18008424 | 6.5 to 8 | PG29 | 40 | 8 | 4x |
