Norm
IP 68 to EN / IEC 60529
Temperature range
-20 C to 70°C
Resistance
Good resistance to alkalis, acids and chemicals
Properties
Highly flexible
Approvals
Conforms to RoHS guideline
Temperature short time
to 80 C
| Partnumber | Inner diameter | Outer Ø | Bending radius |
|---|---|---|---|
| 18112200 | 21 | 27 | 41 |
| 18112250 | 29 | 36 | 54 |
| 18112307 | 38 | 45 | 68 |
| 18112102 | 14 | 19 | 29 |
| 18112001 | 7 | 10 | 15 |
| 18112153 | 16 | 21 | 32 |
| 18112348 | 48 | 56 | 84 |
| 18112056 | 13 | 17 | 26 |
| 18112005 | 10 | 14 | 21 |
